AMD Ryzen 7 5700, 8-Core/16 Threads, Max Freq 4.6GHz, 20MB

Description

AMD Ryzen™ 7 5700

General Specifications

Platform: Boxed Processor
# of CPU Cores: 8
Product Family: AMD Ryzen™ Processors
# of Threads: 16
Product Line: AMD Ryzen™ 7 Desktop Processors
Max. Boost Clock: Up to 4.6GHz
Base Clock: 3.7GHz
L1 Cache: 512KB
L2 Cache: 4MB
L3 Cache: 16MB
Default TDP: 65W
AMD Configurable TDP (cTDP): 45-65W
Processor Technology for CPU Cores: TSMC 7nm FinFET
Unlocked for Overclocking: Yes
CPU Socket: AM4
Socket Count: 1P
Thermal Solution (PIB): AMD Wraith Stealth
Max. Operating Temperature (Tjmax): 95°C
*OS Support
Windows 10 – 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.

Connectivity
PCI Express® Version: PCIe 3.0
System Memory Type: DDR4
Memory Channels: 2
System Memory Specification: Up to 3200MT/s
Max Memory Speed:
2x1R DDR4-3200
2x2R DDR4-3200
4X1R DDR4-2933
4x2R DDR4-2667

Product ID Boxed
100-000000743BOX
